Oxygen-Free Copper (OFC) Bare Wire - Hard - AWG 20 - High Conductivity

Main Features 1) Enameled Copper Wire is one kind of magnet wire which is consisted of bare round copper which accord with EN 13601Cu-ETP standard as the conductor and multi-layer insulation layers. The multi-layer insulation layers can be polyester, modified polyester or polyester-imide and so on. 2) Our Enameled Round Copper Wire is one kind of enameled wire which has high heat resistance. Its temperature class can be from 130℃ to 220℃. 3) Our Enameled Round Copper Wire uses TU2 oxygen-free copper as raw material.TU2 oxygen-free copper has good conductivity and heat conductivity.

Category：

Copper wire

WhatsApp：

8613920018539

Send email to us

Oxygen-Free Copper (OFC) Bare Wire - Hard - AWG 20 - High Conductivity

Insulated Enameled Copper Wire
Enameled copper wire	Type	Q(ZY/XY)-1/200
	Diameter	0.27mm
	Standard	IEC60317
Test Item	Unit	Technical Requirement	Test Result
Specifications	Conductor Size: Measured in American Wire Gauge AWG or circular mils kcmil. Sizes typically range from 14 AWG to 750 kcmil. Smaller AWG numbers represent larger wire diameters. For example, 14 AWG wire has a diameter of approximately 1.63 mm, while 1 AWG wire has a diameter of about 7.35 mm. The number of strands within a stranded wire also varies depending on the size; for instance, 14 AWG through 1 AWG wires often have 7 strands, 1/0 through 4/0 wires usually have 19 strands, 250 through 500 kcmil wires may have 37 strands, and 600 kcmil wires commonly have 61 strands.
Grade	ASTM B552 / EN CW354H ASTM B197 / EN CW101C ASTM B159 / EN CW450K ASTM B134 ASTM B134 / EN CW505LC10200 / OFE C10100 / OFC C11000 / ETP
Elongation		>=22 %	30%
spring-back angle		<=47	43
Flexibility and adhesion	winding test	1D	1
Flexibility and adhesion	Jerk test	No Crack, and No losing adhesion	ok
Heat shock		0.630mm	ok
Cut-through resistance		cut-through resistance	2

product feature
